PCU PRO 5KVA/48V

Amaze Solar PCU PRO is a product of Long Last Power Technologies, the fastest emerging brand in power back-up solutions in India. An inverter with unmatchable performance that is ideal for residence, small commercial establishment.

Capacity: 5 KVA /48V
Rated AC power: 230V (single phase)
Charge Controller - MPPT
Max supported panel power: 5000 Wp

MRP: ₹90,000 Inclusive of all taxes

Quantity:

Enquiry Now

Expected Delivery in 5-7 Business Days.

Capacity

5 KVA /48V
Technology

Pure Sine Wave
Dimensions

30.0*48.4*51.1 CM
Warranty

36 Months

Feature:

MPPT charge controllers are more efficient compared to PWM charge controllers as they convert 30% more power from solar panels.
Gives priority to solar in both backup and charging mode of operation thereby maximizing solar energy utilization.
Allows users flexibility to set priority settings based on their requirement of maximum energy saving, power backup only during power cut and power backup through battery in areas where grid supply is not available.
Solarverter PRO is a BIS certified solar inverter as per IS/IEC standards which is mandatory for all solar inverters.

Specification
Model	PCU PRO 5 KVA
Range Name (Solar)	PCU PRO
VA Rating	5 KVA
Output Waveform	Sine Wave
Warranty	36 Months
Net weight (kg)	54 kg
No. of 12V Batteries in Series	4
Technology (Solar)	With Battery
Maximum Power Voltage Vmp (V)	110V-180V
Max. supported panel power (Wp)	5000Wp
Nominal battery bank voltage	48V
Input Voltage Range (Voc)	130V-220V
Product Quantity	1N (One Number)
Contents	1 N Inverter, 1 N Warranty card
Warranty	36 Months (For detailed terms and conditions of warranty please refer to the warranty card supplied along with the product)
Country of origin	Made in India
Marketed By	Longlast Power Products Limited, Plot No. 94, Sector-5, Pocket N1, Bawana, Delhi 110039
For Consumer Complaint	Longlast Power Products Limited, Plot No. 94, Sector-5, Pocket N1, Bawana, Delhi 110039, Ph.: 9999933039, Email Id: care@amaze-india.com
